Sliding Glass Partition | Jamaica Lane Residence

Acid Etched Sliding Glass Partition in Satin Brass

For this Palm Beach home the primary bath needed a divider that lets light through but keeps privacy, without the swing of a hinged door. ACG Glass & Metals built a full height sliding glass partition that closes off the bath from the adjoining room.

The partition runs on a top mounted OX-XO sliding system, so the two center panels slide open toward the ends and the outer panels stay fixed. The glass is 3/8 inch low iron acid etched monolithic tempered glass, which gives a soft, even white with no green tint and still lets daylight pass from one room to the next.

Every panel is wrapped in a 3/4 inch satin brass U-channel frame to match the brass fixtures of the bath, and the active doors use recessed handles so nothing sticks out when the panels pass each other.

SCOPE
Sliding Glass Partition
LOCATION
Palm Beach, FL
FINISH
Satin Brass Frame
SYSTEM DETAIL 01
Sliding System
Top Mounted OX-XO Sliding System
Two Sliding Center Panels
Fixed Panels at Each End
Recessed Handles on the Active Doors
SYSTEM DETAIL 02
Glass and Frame
3/8" Low Iron Acid Etched Glass
Monolithic Tempered Safety Glass
3/4" Satin Brass U-Channel Frame
Every Panel Wrapped in Brass
PROJECT VALUE: $10K - $15K
STATUS: COMPLETED
